Product Features
1. Support TTL, RC, HSS,wireless triggering (The TTL, HSS, and RC modes require compatible flash triggers to be used)
2. With a special designed MTL mode, support continuous flashes
3. With 2 fisheye wireless signal sensor units. Plus one fiber port, sensor coverage 160 °. Wireless trigger supports M, MTL, HSS. (TTL ,RC needs fiber)
4. GN.ISO 100 : 44 (tested on land)
5. Scattering angle 110 ° （under water）
6. Temp 6200k
7. With dome diffuser, scattering angle 120 °, Temp 5500k
8. Full power recycle time 0.6 second
9. Max diameter 90mm, length of main body 150mm,full length including knobs 177mm
10. Weight on land 1060 grams (without battery, with ball mount),1195 grams with 3x18650 batteries (with ball mount)
11. Weight in water 125 grams (including 3x18650 batteries, including ball mount)
12. Battery: 3x18650 lithium batteries(discharging current equal or over 20A).135 grams total
13. Water proof battery chamber
14. Full power flash : around 800 times
15. With 2 aiming light colors, 250 lumen on white, 180 lumen on red
16. Waterproof Depth : 100m
17. With The Lumilink 2.0 wireless transmitter,synchronize with your camera’s shutter speed up to S1/200.
In shallow water and strong sunlight, it maintains a reliable connection up to 2 meters.
In deep water and dim ambient light, the working distance extends to over 10 meters.
The optical signal for triggering is encrypted, designed to be anti-jam, minimizing interference.
Certified battery procurement channels https://www.orbtronic.com/sony-vtc6-18650-battery-flat-top
·Photos taken on Autosync mode, for TTL testing
SONY A7M4 90MM LENS
S1/250, ISO100, F2.8~F22
testing result by a professional 3rd party, Trt-electronics www.trt-electronics.com
·Photos taken on Autosync mode, for RC testing
OLMPUS TG7
·Photos taken on HSS mode, for HSS testing
SONY A6700
·Photos taken on MTL mode, test for 10FPS continuous shooting
STOP 12 GN22
STOP 9 GN13
10FPS continuous shooting at a power of less than 9 stops can ensure more stable flash brightness
·Photos taken on MTL mode, test for 5FPS continuous shooting
STOP 12 GN22
Light scattering angle for different accessories installed on Apollo III 2.0
